Tank and floor integrity inspection programs.
Overview
Vacuum box testing is a proven method for detecting through-wall leaks in plate seams, fillet welds, and tank floor plates. A transparent box is sealed over the test area; vacuum is applied while a bubble-forming solution is observed. Formation of bubbles indicates a leak path. The technique is widely used during tank construction, repair, and API 653-type floor inspections.
Applications
- Aboveground storage tank floor plate seams and lap welds
- Shell-to-bottom welds and critical fillet joints
- Repair patches and newly fabricated plate assemblies
- Verification of leak-tightness after welding or grinding
Benefits
- Direct visual indication of leak locations
- Effective on large floor areas when performed systematically
- Complements other NDE methods (UT, MFL, visual) in tank programs
- No radiation or complex consumables required
Our Approach
Technicians prepare surfaces, apply solution, and systematically cover the required areas. Results are documented with clear identification of any indications. We coordinate vacuum box work with other tank NDE activities to minimize downtime.
